Shaft Collar, Split, Standard Construction, Set Screw, Cast Iron

Royersford shaft collars are used on moving parts and equipment in many industries as a mechanical stop, mounting other components or as a bearing face. The Solid Collars are manufactured to slip over the shaft and are held in place using set screw(s). The Split Collar allows for the collar to be installed or removed without the need for removing other items from the shaft. The Split Collar is also held in place with set screw(s). Split cast iron collars are used when the removable feature is desirable. They are available from 1 in shaft size to 8 in. Their dimensions are the largest of the three types. Some clamping action is present due to the split style, but the primary positioning force is the socket head set screw.
